Polaris RZR XP4 1000 User Manual

6.30
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
REF.
QTY.
DESCRIPTION REF.
QTY.
DESCRIPTION
1. 1
Fill Plug
44. 1
Gear, Sector 16T
2. 1
Drain Plug, Magnetic
45. 1
Gear, Sector 31T
3. 14
Screw, M8 x 1.25 x 30
46. 1
Pawl, Detent
4. 6
Screw, M6 x 1 x 20
47. 1
Star, Detent
5 3
Screw, M8 x 50
48. 1
Plate, Park, 12-Face
6. 1
Screw, M6 x 1 x 40
49. 1
Shaft, Output 53T
7. 6
Screw, M6 x 1 x 18
50. 1
Shaft, Idler 29T
8. 1
Nut, NyLoc, M8 x 1.25
51. 1
Shaft, Reverse 29T
9. 2
Washer, Cup
52. 1
Shaft, Front Output
10. 3 Washer 53. 1
Shaft, Input Helical
11. 1 Washer 54. 1 Bellcrank
12. 1 Washer 55. 1
Collar, Shift
13. 2
Pin, Dowel
56. 1
Rail, Shift Shaft
14. 1
Pin, Spring
57. 1
Tube, Vent, 1/4 in.
15. 1
Retaining Ring, External
58. 1
Shift Dog, Park
16. 1
Snap Ring
59. 1
Gear, 44T
17. 1
Retaining Ring, External
60. 2
Fork, Shift
18. 1
Retaining Ring, External
61. 1
Sprocket, 48T, 6-Face
19. 1
Retaining Ring, Internal
62. 1
Gear, Low 67T
20. 2
Retaining Ring, External
63. 1
Engagement Dog, 6-Face
21. 2
Retaining Ring, External
64. 1
Gear, 53T
22. 3
Retaining Ring, External
65. 1
Shaft, Pinion 11T
23. 1
Retaining Ring, External
66. 1
Gear, 46T
24. 2
Washer, Thrust
67. 1
Gear, Snorkel 13T
25. 1
Washer, Thrust
68. 1
Shaft, Shift
26. 1 Shim 69. 1
Weldment, Rear Mount Bracket
27. 1 Shim 70. 1
Bracket, Rear Mount
28. 2
Bearing, Needle Cage
71. 1
Cover, Bearing, Center Drive
29. 2
Bearing, Ball
72. 1
Spacer
30. 2
Bearing, Ball
73. 1
Chain, Silent
31. 2
Bearing, Ball
74. 1
Switch, Rotary, 2-Pin
32. 3
Bearing, Ball
75. 1
O-Ring
33. 1
Bearing, Needle Cage
76. 1
O-Ring
34. 1
Bearing, Ball
77. 1
O-Ring
35. 2
Bearing, Ball
78. 1
Seal, Triple Lip
36. 2
Spring, Compression
79. 1
Seal, Dual Lip
37. 2
Spring, Compression
80. 2
Seal, Triple Lip
38. 1
Spring, Compression, Detent
81.
-
N/A
39. 1
Tube, Snorkel
82. 1
Sensor, Speed
40. 1
Cover, Sector Gears
85. 1
Bearing, Ball
41. 1
Case, RH
86. 1
Spring, Wave
42. 1
Case, LH
88. 1
Bracket, Wire Harness
43. 1
Drum, Shift
89. 1
Collar Sleeve, Input Shaft
TRANSMISSION
