9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
Steering / Suspension
ITEM
TORQUE VALUE
Front A-Arm Bolt
42 ft-lb (57 Nm)
Tie Rod End to Bearing
Carrier Housing Bolt (Not
reusable)
15 ft-lbs (20 Nm) + 90°
Ball Joint Fastener
42 ft-lbs (57 Nm)
Front Shock Mount Bolts
44 ft-lb (60 Nm)
Rear Shock Mount Bolts
70 ft-lbs (95 Nm)
Wheel Hub Castle Nuts
110 ft-lbs (149 Nm)
Wheel Nuts (Cast
Aluminum Rims)
120 ft-lbs (163 Nm)
Tie Rod End Jamb Nut
14 ft-lbs (19 Nm)
Radius Rod Fasteners
40 ft-lb (54 Nm)
Bearing Carrier to Trailing
Arm Bolts
42 ft-lb (54 Nm)
Rear Stabilizer Bar Linkage 40 ft-lbs (54 Nm)
Rear Shock Reservoir
Mounting Clamps
35 in-lb (4 Nm)
Rear Stabilizer Bar
Mounting Bracket Bolts
17 ft-lb (23 Nm)
Rear Stabilizer Bar
Locating Clamp Bolts
10 ft-lb (14 Nm)
Shock Guard Screws
14 in-lbs (2 Nm)
Tilt Steering Shock
Fasteners
7 ft-lb (10 Nm)
Steering Pivot Tube
Mounting Fasteners
8 ft-lb (11 Nm)
Steering Wheel Nut 65 ft-lbs (88 Nm)
Steering Shaft to Power
Steering Unit (upper/lower)
(EPS models)
15 ft-lbs (20 Nm)
EPS Cover Screws
8 ft-lb (11 Nm)
Power Steering Unit to
Mount Bracket Bolts
30 ft-lb (41 Nm)
Lower Steering Shaft to
Steering Rack
42 ft-lb (57 Nm)
Power Steering Bracket to
Frame Nuts
16 ft-lb (22 Nm)
ITEM
TORQUE VALUE
Steering Rack Mounting
Bolts
16 ft-lbs (22 Nm)
Hip Bolster Bolts 14 ft-lb (19 Nm)
STEERING / SUSPENSION
