2014 Front Shock Valving RZR XP 1000
COMPRES-
SION
REBOUND CLICKER
1.55 x 0.008 1.50 x 0.01 1.10 x 0.025
1.00 x 0.015 1.10 x 0.01 1.00 x 0.025
1.55 x 0.008 1.45 x 0.01 1.00 x 0.025
1.55 x 0.008 1.30 x 0.01 0.625 x 0.065
1.55 x 0.008 1.20 x 0.01
1.55 x 0.008 1.10 x 0.01
1.55 x 0.008 1.00 x 0.01
1.45 x 0.010 0.90 x 0.01
1.30 x 0.008 0.75 x 0.065
Piston Bleed Orifice: none
2014-2015 Front Shock Valving RZR XP 4
1000
COMPRES-
SION
REBOUND CLICKER
1.55 x 0.008 1.50 x 0.01 1.10 x 0.025
1.00 x 0.015 1.10 x 0.01 1.00 x 0.025
1.55 x 0.008 1.45 x 0.01 1.00 x 0.025
1.55 x 0.008 1.30 x 0.01 0.625 x 0.065
1.55 x 0.008 1.20 x 0.01
1.55 x 0.008 1.10 x 0.01
1.55 x 0.008 1.00 x 0.01
1.45 x 0.010 0.90 x 0.01
1.30 x 0.008 0.75 x 0.065
1.20 x .012
1.10 x .012
Piston Bleed Orifice: none
2015 Front Shock Valving RZR XP 1000
COMPRES-
SION
REBOUND CLICKER
0.900 x 0.008 0.900 x 0.015 1.10 x 0.025
0.900 x 0.010 0.900 x 0.012 1.00 x 0.025
1.45 x 0.010 1.45 x 0.015 1.00 x 0.025
0.900 x 0.008 1.45 x 0.015 0.625 x 0.065
1.45 x 0.015 1.45 x 0.008
COMPRES-
SION
REBOUND CLICKER
1.30 x 0.015 1.45 x 0.008
1.20 x 0.015 1.30 x 0.010
1.10 x 0.015 1.00 x 0.008
1.00 x 0.015 1.50 x 0.120
0.750 x 0.065
Piston Bleed Orifice: none
2015 Front Shock Valving RZR XP 1000 High
Lifter
COMPRES-
SION
REBOUND CLICKER
1.55 x 0.008 1.30 x 0.015 1.10 x 0.012
1.00 x 0.015 1.30 x 0.015 0.700 x 0.006
1.55 x 0.008 1.20 x 0.012 1.00 x 0.025
1.55 x 0.008 1.10 x 0.012 0.625 x 0.065
1.55 x 0.008 1.00 x 0.012
1.55 x 0.008 0.900 x 0.012
1.55 x 0.008 1.00 x 0.095
1.45 x 0.010
1.30 x 0.008
Piston Bleed Orifice: 0.100”
Front Shock Valving RZR XP 1000 Desert
Edition
COMPRES-
SION
REBOUND CLICKER
0.900 x 0.008 0.900 x 0.015 1.10 x 0.025
0.900 x 0.010 0.900 x 0.012 1.00 x 0.025
1.45 x 0.010 1.45 x 0.015 1.00 x 0.025
0.900 x 0.008 1.45 x 0.015 0.625 x 0.065
1.45 x 0.015 1.45 x 0.008
1.30 x 0.015 1.45 x 0.008
1.20 x 0.015 1.30 x 0.010
1.10 x 0.015 1.00 x 0.008
1.00 x 0.015 1.50 x 0.120
0.750 x 0.065
Piston Bleed Orifice: none
