Polaris RZR XP4 1000 User Manual

8.34
9925724 R01 - 2014-2015 RZR XP 1000 / RZR XP4 1000 Service Manual
© Copyright 2014 Polaris Industries Inc.
REAR SHOCK DESIGN DETAILS
Travel
12.09″ (30.71 mm)
Extended Length 34.36″ (87.27 mm)
IFP Location RZR XP
1000 / Desert Edition
6.25″ (158.8 mm)
IFP Location RZR XP 4
1000 / High Lifter
7.25″ (184.15 mm)
Nitrogen Pressure 125 psi (862 kPa) +/- 5%
Gas Shock Oil P/N
2874124 (qt.)
2014 Shock Valving RZR XP 1000
COMPRES-
SION
REBOUND CLICKER
1.55 x 0.008 1.500 x 0.01 1.00 x 0.015
1.00 x 0.010 1.45 x 0.01 1.00 x 0.015
1.55 x 0.008 1.30 x 0.01 0.90 x 0.015
1.55 x 0.008 1.20 x 0.01 0.70 x 0.015
1.55 x 0.008 1.10 x 0.01 0.70 x 0.015
1.55 x 0.008 1.00 x 0.01
1.55 x 0.008 0.90 x 0.01
1.45 x 0.010 0.80 x 0.01
1.30 x 0.012
0.75 x 0.065
(top-out)
1.20 x 0.012
1.50 x 0.125
(top-out)
Piston Bleed Orifice: 0.100″
2014-2015 Shock Valving RZR XP 4 1000
COMPRES-
SION
REBOUND CLICKER
1.55 x 0.008 1.50 x 0.01 1.00 x 0.015
1.00 x 0.010 1.45 x 0.01 1.00 x 0.015
1.55 x 0.008 1.30 x 0.01 0.90 x 0.015
1.55 x 0.008 1.20 x 0.01 0.60 x 0.015
1.55 x 0.008 1.10 x 0.01 0.60 x 0.015
1.55 x 0.008 1.00 x 0.01
1.55 x 0.008 0.90 x 0.01
1.45 x 0.010 0.80 x 0.01
1.10 x 0.012
0.75 x 0.065
(top-out)
1.00 x 0.012
1.50 x 0.125
(top-out)
Piston Bleed Orifice: 0.100″
2015 Shock Valving RZR XP 1000
COMPRES-
SION
REBOUND CLICKER
1.55 x 0.010 1.500 x 0.008 1.00 x 0.015
1.20 x 0.008 0.900 x 0.008 1.00 x 0.015
1.55 x 0.010 1.45 x 0.008 0.90 x 0.015
1.20 x 0.008 1.30 x 0.008 0.70 x 0.015
1.50 x 0.010 1.20 x 0.008 0.70 x 0.015
1.45 x 0.010 1.10 x 0.008
1.30 x 0.010 1.00 x 0.008
1.20 x 0.010 0.900 x 0.008
1.10 x 0.012
0.75 x 0.065
(top-out)
0.900 x 0.012
0.800 x 0.012
1.50 x 0.125
(top-out)
No Piston Bleed Orifice
STEERING / SUSPENSION
