Page 112
Alarm ID
Description
Setpoints
6= In bounds
Relay goes “ON” if
value is inside the zone
between the two
setpoints.
Relay Setpoints,
P*213, 223, 233,
243, 253, 263 and
P*214, 224, 234,
244, 254, 264 can
be set in any order
as the unit ‘knows’
that you are setting
an in bounds alarm.
7= Out of bounds
Relay goes “ON” if
value is outside the zone
between the two
setpoints.
Relay Setpoints
P*213, 223, 233,
243, 253, 263 and
P*214, 224, 234,
244, 254, 264 can
be set in any order
as the unit ‘knows’
that you are setting
an out of bounds
alarm.
When P*211, 221, 231, 241, 251, 261 = 4 (Loss of Echo) or 5 (Loss of
Clock)
The third parameter has no function and will not be displayed.
