Page 113
When P*211, 221, 231, 241, 251, 261 = 6 (Device Fail)
This parameter defines which failed device relay, the alarm should respond
to, as follows.
Alarm ID
Description
Setpoints
1 = Fail Rel.1
Relay goes “ON” when a device
failure is detected on relay 1.
None
2 = Fail Rel.2
Relay goes “ON” when a device
failure is detected on relay 2.
None
3 = Fail Rel.3
Relay goes “ON” when a device
failure is detected on relay 3.
None
4 = Fail Rel.4
Relay goes “ON” when a device
failure is detected on relay 4.
None
5 = Fail Rel.5
Relay goes “ON” when a device
failure is detected on relay 5.
None
6 = Fail Rel.6
Relay goes “ON” when a device
failure is detected on relay 6.
None
7 = Any 1 Fail
Relay goes “ON” when a device
failure is detected on any 1
relay.
None
8 = Any 2 Fail
Relay goes “ON” when 2 device
failures are detected on any 2
relays.
None
