The third parameter for each relay determines the assignment or
condition of the relay, where required.
P*212, P*222, P*232, P*242, P*252, P*262 Relay Alarm ID/Pump Group,
When P*211, 221, 231, 241, 251, 261 = 1 (Time), or 3 (General Control)
This parameter has no function and will not be displayed.
When P*211, 221, 231, 241, 251, 261 = 2 (Step Time)
If the relay is selected for Step Time, then this parameter is used to assign
the relay to the 0 = Open condition (increase level) or 1 = Close condition
(decrease level).
The fourth parameter, fifth parameter and sixth parameter are set to
determine the switch points, “ON” and “OFF” for the relay and where
required the order of start. See control function, table (P*211, 221, 231,
241, 251, 261) for further information.
When P*211, 221, 231, 241, 251, 261 =1 (Time)
P*213, P*223, P*233, P*243, P*253, P*263 Relay Setpoint 1
This parameter determines the “Time Period” that the relay will remain “ON”.
Relay Setpoints are entered in Minutes.
See the appropriate relay Function tables (P*211, 221, 231, 241, 251, 261) for
further information.
P*214, P*224, P*234, P*244, P*254, P*264 Relay Setpoint 2
This parameter determines the “Cycle Time” for the operation of the relay.
See the appropriate relay Function tables (P*211, 221, 231, 241, 251, 261) for
further information.
