Pulsar ULTRA TWIN User Manual

Page 148
P1-601to 603, P2-601 to 603 Vessel Dimensions
These three parameters are used to enter the dimension required to calculate
the volume. The dimensions required are as shown below and are entered
Measurements Units (P*104).
Vessel Shape
P1-601
P2-601
P1-602
P2-602
P1-603
P2-603
P1-600, P2-600 = 0
Cylindrical Flat base
Cylinder
Diameter
P1-600, P2-600 = 1
Rectangular Flat base
Width of
rectangle
Breadth of
rectangle
P1-600, P2-600 = 2
Cylindrical Cone base
Height of
base
Cylinder
Diameter
P1-600, P2-600 = 3
Rectangular Pyramid base
Height of
base
Width of
rectangle
Breadth of
rectangle
P1-600, P2-600 = 4
Cylindrical Parabola base
Height of
base
Cylinder
Diameter
P1-600, P2-600 = 5
Cylindrical Half-sphere base
Cylinder
Diameter
P1-600, P2-600 = 6
Cylindrical Flat sloped base
Height of
base
Cylinder
Diameter
P1-600, P2-600 = 7
Rectangular Flat sloped base
Height of
base
Width of
rectangle
Breadth of
rectangle
P1-600, P2-600 = 8
Horiz. cylinder, flat ends
Length of
Cylinder
Cylinder
Diameter
P1-600, P2-600 = 9
Horiz. Cyl. parabolic ends
Length of
Cylinder
Cylinder
Diameter
Length of
one end
section
P1-600, P2-600 = 10
Sphere
Sphere
Diameter
P1-604, P2-604 Calculated Volume
This parameter displays the maximum volume that has been calculated by
the Ultra Twin and is a Read Only parameter. The volume displayed will be
shown in volume units (P1-605, P2-605) and is the total volume available
between empty level (P1-105, P2-105) and 100% of span (P1-106, P2-
106).
