Page 149
P1-605, P2-605 Volume Units
This parameter determines the units that you wish to display, for volume
conversion. It is used in conjunction with P1-607, P2-607 (maximum
volume), and the units are shown on the display (subject to P1-810, P2-
810). The choices are:
Option
Description
0 = No Units
Volume will be totalised with no units
1 = Tons
Volume will be totalised in Tons
2 = Tonnes
Volume will be totalised in Tonnes
3 = Cubic metres
Volume will be totalised in cubic metres
4 = Litres
Volume will be totalised in litres
5 = UK Gallons
Volume will be totalised in UK Gallons
6 = US Gallons
Volume will be totalised in US Gallons
7 = Cubic feet (Default)
Volume will be totalised in cubic feet
8 = Barrels
Volume will be totalised in barrels
9 = lbs (pounds)
Volume will be totalised in lbs (pounds)
P1-606, P2-606 Correction Factor
This parameter is used to enter a correction factor, when required, such as
the specific gravity of the material so that the volume calculated is relative
to the actual amount of material that can be contained between empty level
(P1-105, P2-105) and 100% of span (P1-106, P2-106). Default = 1
P1-607, P2-607 Max Volume
This parameter displays the actual maximum volume that has been
calculated by the Ultra Twin, i.e. P1-604, P2-604 Calculated Volume x
P1-606, P2-606 Correction Factor, and is a Read Only parameter. The
volume displayed will be shown in P1-605, P2-605 Volume Units and is
the total volume available between empty level (P1-105, P2-105) and 100%
of span (P1-106, P2-106).
