Pulsar ULTRA TWIN User Manual

Page 41
Parameter
Default
Description
P213 / P214
Relay 1
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Either Alarm or Level control.
Depends on application.
P223 / P224
Relay 2
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Level control.
Depends on application.
P233 / P234
Relay 3
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Level control.
Depends on application.
P243 / P244
Relay 4
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Level control.
Depends on application.
P253 / P254
Relay 5
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Level control.
Depends on application.
P263 / P264
Relay 6
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Level control.
Depends on application.
P830
mA Out Range
2= 4 to 20 mA
Determines the mA output
range.
0 = Off, 1 = 0 to 20mA,
2 = 4 to 20mA, 3 = 20 to
0mA, 4 = 20 to 4mA.
P870
Fill Damping
32.80 ft/min
Rate of maximum fill rate (set
above the actual fill rate of the
vessel).
P871
Empty Damping
32.80 ft/min
Rate of maximum empty rate
(set above the actual empty
rate of the vessel).
