Pulsar ULTRA TWIN - Page 64

Page 56
Parameter
Default
Description
P101 Transducer
2 = dB6
Type of transducer being used.
P104
Measnt. Units
4 = feet
Select units to be used for
programming measurement
information.
P105
Empty Level
19.685 feet
Distance from the face of the
transducer to the material at the
bottom of the vessel.
P106
Span
10.701 feet
Distance from the empty level (0%
full) to span (100% full).
For More Options Hit Enter
Parameter
Default
Description
P213 / P214
Relay 1
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Either Alarm or Pump control.
Depends on application.
P223 / P224
Relay 2
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P233 / P234
Relay 3
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P243 / P244
Relay 4
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P253 / P254
Relay 5
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
P263 / P264
Relay 6
ON/OFF
setpoints
Factory preset as a %
to appropriate level
according to the span
already entered.
See tables below
Depends on
application
Either Alarm or Pump control.
Depends on application.
