Pulsar ULTRA TWIN User Manual

Page 58
Application
Number of
Pumps
Pump
Number
On
Setpoint
Off
Setpoint
Pump Up
One
Pump 1
50%
80%
Pump Up
Two
Pump 1
Pump 2
50%
30%
80%
80%
Pump Up
Three
Pump 1
Pump 2
Pump 3
50%
40%
30%
80%
80%
80%
Pump Up
Four
Pump 1
Pump 2
Pump 3
Pump 4
60%
50%
40%
30%
80%
80%
80%
80%
Pump Up
Five
Pump 1
Pump 2
Pump 3
Pump 4
Pump 5
60%
50%
40%
30%
25%
80%
80%
80%
80%
80%
Pump Up
Six
Pump 1
Pump 2
Pump 3
Pump 4
Pump 5
Pump 6
60%
50%
40%
30%
25%
20%
80%
80%
80%
80%
80%
80%
Relay
Function
Relay I.D.
On
Setpoint
Off
Setpoint
Alarm
HiHi
90%
85%
Alarm
High
85%
80%
Alarm
Low
10%
15%
Alarm
LoLo
5%
10%
Note
When using the Quick Setup Menu relays will be allocated to the
point of measurement you are currently setting up and the
availability of relays will depend on the number of relays used when
setting up the previous point of measurement via the Quick Setup
Menu for that point.
