Pulsar ULTRA TWIN User Manual

Page 69
The default values used for determining the relay setpoints, when setting
Alarm relays, via the Quick Setup menu are entered as a % of span and are
as follows.
Relay Function
Alarm ID
On
Setpoint
Off
Setpoint
Alarm
Hi Hi
90%
85%
Alarm
High
85%
80%
Alarm
Low
10%
15%
Alarm
Lo Lo
5%
10%
Note
When using the Quick Setup Menu relays will be allocated to the
point of measurement you are currently setting up and the
availability of relays will depend on the number of relays used when
setting up the previous point of measurement via the Quick Setup
Menu for that point.
