Qirod QD100 Series User Manual

104
fault (troubleshooting)
e-11
Undervolta
ge fault

Abnormal
fluctuation of
input voltage;
Power network
capacity higher
than 200 kVA;
There is
switchable
capacitor to
improve power
factor on the
power network;
Machine that
SCRs is
connected to the
power network.

Inverter starts
the load already
in rotation.

There is
possible phase
failure.

The
deceleration
time is too short.

Install input reactor
or use braking
resistance.

Adopt
forward/reverse speed
tracking and restart
function (STR function)
(f500 = 1)

Set f418 = 2.

Determine the cause
of output phase failure
(such as poor
connection, open
circuit of output or
open circuit of motor
winding) and correct it.

Increase the
deceleration time (f011
or f519)

Enable overvoltage
fault protection (f415).
e-12
DC bus
undervolta
ge fault

Input voltage
is too low.

Check input voltage.

Set f417 to select
alarm or tripping.
Code of
fault
Type of fault
Possible cause
Measures
(troubleshooting)
