Qirod QD100 Series User Manual

138
NO.
Parameter
Name
Setting Range default
WRT
User
setting
f304
Input
terminal
function for
LI4
64:Acceleration/deceleration
curve 3
65:Acceleration/deceleration
curve 3 + forward running
command
66:Acceleration/deceleration
curve 3 + reserve
running command
67:Command source switch
68:Command source +
frequency source switch
69:3-wire control stop
counter
70:Simple PLC stop reset
71:Simple PLC pause
0 ●
f305
AI1 voltage-
current input
selection
0:0～5V voltage signal input.
1:0～10V voltage signal
input.
2: 0-20mA(4-20mA) current
signal input.
0 ●
f306
sink/source
mode
selection
0: Source (Positive) logic
terminal mode.
1: Sink (Negative) logic
terminal mode
1 ●
f307
AO voltage-
current
output
selection
0: Current signal output.
1: Voltage signal output.
1 ●
f308
Input
terminal
function of
AI1
f301~f304 0 ●
f309
Always-
active
terminal
selection 1
f301~f304 1 ●
