Qirod QD100 Series User Manual

139
NO.
Parameter
Name
Setting Range default
WRT
User
setting
f310
Always-
active
terminal
selection 2
f301~f304 0 ●
f311
Output
terminal
function A of
LO-CLO
f315 4 ●
f312
Output
terminal
function B of
LO-CLO
f315 255 ●
f313
AI2 terminal
function
selection
0: AI2 - analog input
1: AI2 - contact input (Sink)
2: AI2 - contact input
(Source)
0 ●
f314
Input
terminal
function of
AI2
f301~f304 0 ●
f315
Output
terminal
function A of
T1 (T1A-
T1B-T1C)
0:Frequency lower limit
2:Frequency upper limit
4:Low speed
6:ACC/DEC complete
8:Speed reach (f338)
10:Speed reach2 (f338)
12:FB(AI1) equal frequency
command
14:FB(AI2) equal frequency
command
16:AI1 reach f340
18:AI1 reachf342
20:AI2 is final selected FC
22:Inverter run
24:echo back signal (ready
without ST/RUN
command)
26:Forward
、
reverse
running
40 ●
