Qirod QD100 Series

143
NO.
Parameter
Name
Setting Range default
WRT
User
setting
f341
AI1 input
reach
detection
band
0~20% 3 ○
f342
AI2 input
reach
detection
level
0~100% 0 ○
f343
AI2 input
reach
detection
band
0~20% 3 ○
f344
Frequency
command
agreement
detection
range
0.0 Hz ~f007 2.5 ○
f345
Logic
output/pulse
train output
selection
(LO-CLO)
0: Logic output
1: Pulse train output
0 ●
f346
Pulse train
output
function
selection (LO
-CLO)
0: Output frequency
1: Output current
2: Set frequency (Before
PID)
3: Frequency setting value
(After PID)
4: DC voltage
5: Output voltage command
value
6: Input power
7: Output power
8: AI1 Input value
9: AI2 Input value
10: Torque
11: Torque current
0 ○
