Qirod QD100 Series

144
NO.
Parameter
Name
Setting Range default
WRT
User
setting
f346
Pulse train
output
function
selection (LO
-CLO)
12: Motor cumulative load
factor
13: Inverter cumulative load
factor
14:PBR (braking reactor)
cumulative load factor
0 ○
f347
Maximum
numbers of
pulse train
500~1600 800 ○
f348
AO1
selection
0:Output frequency
1:Output current
2:Set frequency (before PID)
3:Frequency setting value
(after PID)
4:DC voltage
5:Output voltage command
value
6:Input power
7:Output power
8:AI1 input
9:AI2 input
10:Torque
11:Torque current
12:Motor cumulative load
factor
13:Inverter cumulative load
factor
14:brake resistor cumulative
load factor
15:Serial communication
data
16:For adjustments (f349 set
value is displayed.)
0 ○
f349
AO gain
adjustment
0~1280
varies
by
model
○
f350
Inclination
characteristic
of analog
output
0
：
Negative
1
：
Positive
1 ○
