19
Note 2: In the case when there is no valid frequency command (e.g, frequency command
is under starting frequency setting f503), the motor does not run even if the
inverter receives the RUN command. At this time the RUN led on the keypad
blinks.
Note 3: When f003 = 7, use f830 as the PID setting.
NO. Parameter Name Setting Range Default
f004 Command mode selection 2 0~2 0
0: Terminal board. Terminals Ll 1 to Ll5 (can be defined terminal functions) controls
running operation.
1: Keypad. Press the <RUN> and <STOP>/<RESET> keys on the keypad to start and
stop.
2: Serial communication. Run and stop through serial communication.
Note: Switching operation between f002and f004 can be set input terminal function 67
(or 68) beforehand to an input contact terminal. When switching the terminal operation
mode to panel operation mode:
If f502 = 1, the motor will keep the running status before switch operation.
If f502 = 0, the motor stops regardless the running status before the switch operation.
NO. Parameter Name Setting Range Default
f005 Frequency setting mode selection 2
0~7 2
Setting method is the same as f003.
Note: About switching between f003 and f005operation, see f006.
NO. Parameter Name Setting Range
0~1 0
0: f003 is switchable to f005 by the input terminal (Input terminal function 20).
1: f003.
Switching between the frequency commands specified with f003 and f005 can be made
by entering a command from a input contact terminal. To do so, however, the frequency
command forced switching function (input terminal function 20) needs to be set
beforehand to an input contact terminal.
If OFF: The frequency command specified with f003 will be selected.
To Next Page
