Raider 50 - Gear Case (Drive Shaft, MWX50)

Lower Unit
RO
Gear Case (Drive Shaft, MWX50)
OBM
OBM
A
OBM
LIT OBM
OBM LIT
OBM
OBM
OBM
GEAR
GEAR
P/L Fig. 15
TEF
TEF
GEAR
GEAR
OBM
OBM
G17
G17
1342
1342
OBM
GEAR
GEAR
OBM
OBM
OBM
OBM
OBM
OBM
OBM
G17
G17 GEAR
GEAR
OBM
OBM
1342
1342
1342
1342
1342
1342
Ref.
No.
Description Q'ty Remarks
Ref.
Description Q'ty Remarks
No.
1 Gear Case Ass'y 1 with Sub Water Pipe 14 Water Pipe Seal (Lower) 1
2 Roller Bearing 25-33-30 1 Do not reuse. 15 Pump Case (Lower) 1
3 Bevel Gear B 1 16 Shim 36.9-30-0.5 1
4 Nut (Bevel Gear B) 1 17 Oil Seal 22-37-8 2 Do not reuse.
5 Shim 44-50.5-0.1 A 18 O-Ring 3.2-47 1 Do not reuse.
5 Shim 44-50.5-0.15 A
Selection if necessary
19 Dowel Pin 4-10 2
5 Shim 44-50.5-0.3 A 20 Water Pump Guide Plate 1
6 Drive Shaft (L) 1 21 Guide Plate Gasket 1
Do not reuse.
7 Ball Bearing 6205R 2
Do not reuse.
22 Pump Case Gasket 1 Do not reuse.
8 Drive Shaft Spring 1 23 Bolt 8-80 4
9 Drive Shaft Spring Guide 1 24 Washer 4
10 Water Pump Impeller 1 25 Sub-Water Inlet Strainer 1
11 Key 1 26 Screw 2
12 Pump Case Sub-Ass'y (Upper) 1 27 Clutch Cam 1
13 Pump Case Liner 1 28 Cam Rod (L) 1
6-14
2st 50D2 2011
