Raider 50 - Disassembling Tilt Mechanism

Bracket
GB
15) Disassembling tilt mechanism
1. Set tilt stopper lever to "release" side, and then, remove
tilt stopper setting plate 1.
1
2. Remove tilt stopper 2, bushing 3, set piece 4 and
spring 5.
5
4
3
2
7-50
2st X50D2 2011
