Raider 50 - Removing Bottom Cowl

Bracket
GB
4) Removing Bottom Cowl
1. Remove power unit. Refer to “Removing Power Unit” in
2
chapter 5.
2. Remove snap retainer 1. And then, remove shift rod lever
2.
1
3. Remove shift rod 3.
3
4. Loosen and remove four bolts that secure bottom cowl to
engine base.
5. Remove bottom cowl.
7-24
2st X50D2 2011
