Raider 50 - Inspection of Gear Case

Lower Unit
GB
This work can be done also by using the following tool
kit.
MX50
Roller Bearing Puller Kit :
P/N. 3C8-72700-0
w
w Outer Race Do not reuse.
w
b
a
6-68
MWX50
Roller Bearing Puller Kit :
P/N. 3B7-72700-0
2. Remove taper roller bearing outer race w.
Put the slide hammer in the gear case, hook claw of slide
hammer on the outer race to fix it, and slide the hammer to
pull out the outer race.
Slide Hammer Ass’y :
P/N. 3AC-99080-0
Confirm the position of insertion groove in the
back of outer race, and put the claw of slide
hammer in the groove.
This work can also be done by using the following tool.
Bevel Gear Bearing Puller Ass’y :
MX50:P/N. 3A3-72755-0
MWX50:P/N. 3B7-72755-0
29) Inspection of Gear Case
1. Check skeg a and torpedo-like area b for crack and
other damage.
Replace if necessary.
2st 50D2 2011
