Raider 50 - Assembling Extension Housing

Bracket
GB
MWX50 Only
10) Assembling Extension Housing
1. Align notches a inside the tube joint 1 with hole b of the
extension pipe 2, then insert.
1
a
Passage c for adjusting water flow. Check the
passage for clogged by salt, clean if necessary.
1
OBM
OBM
a
2
b
2
c
2. Insert tube joint 1 and extension pipe 2 to extension
1
housing 3, as shown.
3
2
3. Insert tube joint 1 to the water pipe 4 and attach
extension housing.
4
1342
1342
1342
1
1342
3
7-40
2st X50D2 2011
