Power Unit
Piston & Crank Shaft
2st
2st OIL
2st
2st OIL
2st
2st OIL
P/L Fig. 2
LIT
LIT
2st
2st OIL
2st
2st OIL
2st
2st OIL
2st
2st OIL 2st
2st OIL
A
LIT
LIT
2st
2st OIL
2st OIL
2st
Ref.
No.
Description Q'ty Remarks
Ref.
Description Q'ty Remarks
No.
1 Crankshaft Ass'y W/Gear 1 7-2 Piston Ring (0.5 O/S) 3 OPT 2nd
2 Main Bearing 6305 1
Do not reuse.
8 Piston Pin 3
3 C-Ring d=25 1
Do not reuse.
9 Needle Roller Bearing 75
4 Washer 1 10 Small End Bearing Washer 6
5-1 Piston 3 STD 11 Piston Pin Clip 6
5-2 Piston (0.5 O/S) 3 OPT 12 Main Bearing 1
6-1 Piston Ring 3 STD 1st 13 Oil Seal 32-42-6 1
Do not reuse.
6-2 Piston Ring (0.5 O/S) 3 OPT 1st 14 O-Ring 2.4-39.7 1
Do not reuse.
7-1 Piston Ring 3 STD 2nd 15 Thrust Plate 2
5-24
To Next Page
