Raider 50 - Page 90

Power Unit
GB
P/L Fig. 1
1 € ‚ƒ„… ƒ † € ‚ƒ„… ƒ †
2 € ‚ƒ„… ƒ †
3 € ‚ƒ„… ƒ †
4 € ‚ƒ„… ƒ †
A
€ ‚ƒ„… ƒ †
B
2st
2st OIL
518
518
LIT
LIT
B
A
1 €
2 €
2st
2st OIL
‚ƒ„… ƒ †
‚ƒ„… ƒ †
1
2
LIT
LIT
2st OIL
2st
518
€ ‚ƒ„… ƒ †
518
€ ‚ƒ„… ƒ †
Ref.
No.
Description Q'ty Remarks
Ref.
Description Q'ty Remarks
No.
27 Exhaust Cover (Inner) 1
42 Clip 3
28 Exhaust Cover Gasket 2
Do not reuse. 43 Clip 3
29 Bolt 14
44 Spark Plug (B8HS10) 3
30 Washer 14
45 Clamp 6.5-47.5P 1
31 Bolt 1
46 Bolt 1
32 Gasket 8.1-15-1 1
Do not reuse. 47 Bolt 1
33 Anode 1
48 Nut 1
34 Bolt 1
49 Engine Basement Gasket 1 Do not reuse.
35 Cover 1
50 Crankcase Head 1
36 Gasket 1
Do not reuse. 51 O-Ring 1.7-59 1
Do not reuse.
37 Bolt 2
52 Oil Seal 25-40-8 1 Do not reuse.
38 Hose 1 98AL-401000
53 Oil Seal 16-28-7 1
Do not reuse.
39 Hose 1 98AL-401000
54 Bolt 2
40 Hose 1 98AL-401000
41 Check Valve 3
5-22
2st X50D2 2011
