Raider 50 - Inspection Items

Bracket
GB
2. Inspection Items
1) Inspection of Throttle Cable
1. Check operation of throttle cable.
2. Check throttle cable inner wire and outer wire for bend and
damage. Replace if necessary.
2) Removing of Tiller Handle
1. Remove advancer arm 1.
1
2. Remove throttle wire mounting clamp 2 and screw 3.
3
2
3. Remove throttle grip 4 and throttle shaft supporter 5.
4
5
4. Remove tiller handle holder installation nut 6.
6
7-18
2st X50D2 2011
