Power Unit
GB
1. Special tools
1 2
3T1-72781-0
3
3B7-72785-0
3B7-72783-0 3C7-72783-0 940191-0800 3B7-72784-0
Eye Bolt (Powerhead Lift Ring) Flywheel Puller Kit Piston Pin Tool
P/N. 3T9-72212-0 P/N. 3T1-72211-0 P/N. 345-72215-0
Used to hook power unit when
hanging
Removing or attaching flywheel
Removing piston pin
4 5 6 7
Piston Ring Tool Universal Puller Plate Roller Setting Piece Piston Pin Tool
P/N. 353-72249-0 P/N. 3AC-99750-0 P/N. 3LC-72216-0 P/N. 3LC-72215-0
Removing or attaching piston
rings
Removing main bearing Installing roller bearing Installing piston pin
5-2
2st X50D2 2011
