Fuel System
10) Adjusting Float Height
a
2
1. Measure float height as shown, and replace float if out of
specification.
Float Height a :
14.5 1mm 0.571 0.039in
2. Install drain screw, float chamber 1 and cover 2.
1
CAUTION
Do not adjust float height by knotting the
fishing line, etc. It promotes wear of the
needle valve and can cause malfunction of
the engine.
11) Installing Carburetors
1. Reverse carburetor removing steps to install.
4-30
2st 50D2 2011
