Service Information
y u i o
ø31.5 x ø25 x H32
Roller Bearing Attachment
Bevel Gear Nut Socket Driver Rod Center Plate
MX50:P/N. 3MC-99710-0
P/N. 346-72232-0 P/N. 3AC-99702-0 P/N. 3AC-99701-0
MWX50:P/N. 3LC-99710-0
Removing or attaching pinion
(B) gear nut
Used in combination with center
place and various attachments
Removing or installing propeller
shaft housing bearing
Used in combination with driver rod and center plate
Attaching propeller shaft housing needle bearing
p a s d
Roller Bearing Puller Kit
Bevel Gear Bearing Install Tool Roller Bearing Press Kit
MX50:P/N. 3C8-72700-0
Slide Hammer Ass'y
P/N. 3C8-72719-0 P/N. 3LC-72900-0
MWX50:P/N. 3B7-72700-0
P/N. 3AC-99080-0
Installing forward (A) gear
Removing or attaching gear case
Removing or attaching gear case and
Removing forward (A) gear
bearing needle bearing propeller shaft housing needle bearing bearing outer race
f
Bevel Gear Bearing Puller Ass'y
g
3B7-72731-0
3B7-72732-0
3B7-72733-0
h
Shimming Gauge
j
MX50:P/N. 3A3-72755-0 Bearing Outer Press Kit
MX50:P/N. 3C8-72250-0
Thickness Gauge
MWX50:P/N. 3B7-72755-0 P/N. 3B7-72739-1
MWX50:P/N. 353-72250-0
P/N. 353-72251-0
Removing forward (A) gear bearing
outer race
Attaching forward (A) gear
bearing outer race
Adjusting pinion (B) gear
height
Measuring gaps
k l ; z
Backlash Measuring Tool Kit
Backlash Measuring Tool Kit
Dial Gauge Plate
Backlash Measuring Tool Clamp
MX50:P/N. 3C8-72234-1
MWX50:P/N. 3B7-72234-0
P/N. 3B7-72729-0
P/N. 3B7-72720-0
Used to attach dial gauge
when measuring backlash
Measuring backlash between forward
(A) gear and pinion (B) gear
Used to attach dial gauge
when measuring backlash
Measuring backlash
