Raider 50 - Page 176

Lower Unit
GB
MWX50
Roller Bearing Press Kit :
P/N. 3LC-72900-0
Bearing Outer Press Guide 8 :
wt
y
e
r
8
9
0q
7
0
7
q
P/N. 3T1-72765-0
Roller Bearing Press Rod 9 :
P/N. 3LC-72767-0
Roller Bearing Press 0 :
P/N. 3S7-72770-0
O Ring q :
P/N. 6H6-07422-0
Washer M8 w :
P/N. 940191-0800
Roller Bearing Outer Press Collar e :
P/N. 3C7-72768-0
Roller Bearing Outer Press Bolt r :
P/N. 3C7-72766-0
Bolt M8-110 t :
P/N. 3C7-72773-0
Roller Bearing Press Flange y :
P/N. 3AC-72901-1
Roller Bearing Press Guide u :
P/N. 3S7-72905-0
GEAR
6-74
u
GEAR
Installation Depth a :
201 mm (7.913 in)
This work can be done also by using the following
tool kit.
MWX50
Roller Bearing Puller Kit :
P/N. 3B7-72700-0
2st 50D2 2011
