Raider 50 - Page 201

Bracket
GB
P/L Fig. 17
OBM
OBM
OBM 1342
OBM
1342
OBM
OBM
OBM
OBM OBM
OBM
OBM
OBM
OBM
OBM
OBM
OBM
OBM
OBM
1342
1 342
Ref.
No.
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
Description
Damper (Lower)
Bolt
Washer 13-34-3
Damper 21-36-5
Nylon Nut 12-P1.75
Washer
Mount Holding Plate (Lower)
Bolt
Stud
Rubber Mount (Upper)
Bolt
Damper (Upper)
Washer
Lock Plate
Mount Holding Plate (Upper)
Q'ty Remarks
1
2
2
2
2
4
2 Rubber Mount Cap (Lower)
4
2
2
2
2
2
1
1 Rubber Mount Cap (Upper)
Ref.
Description Q'ty Remarks
No.
46 Bolt 3
47 Ground L=210 1
48 Ground L=130 1
49 Bolt 2
50 Ground L=110 1
51 Bolt 1
52 Anode 1 OPT
53 Bolt 2 OPT
54 Spring Washer 2 OPT
55 Clamp Screw Kit 2
56 Clamp Screw 1
57 Clamp Screw Handle 1
58 Rivet 3-22 1 Do not reuse.
59 Clamp Screw Pad 1
60 Shoulder Bolt 1 Do not reuse.
