Maintenance
GB
5. Turn the No.2 and No.3 throttle lever screws 4 clockwise
to loosen the throttle butterfly valves.
4
6. Loosen throttle stop screw 5 on top carburetor so it dose
not make contact with throttle lever 6. All throttle butterfly
5
valve should return to a fully closed position a.
6
a
7. Tighten the No.2 and No.3 throttle lever screw 7
8
counterclockwise while pulling upward throttle link rod 8
on the carburetor.
7
3-28
2st X50D2 2011
