Raider 50 - Page 86

Power Unit
GB
P/L Fig. 7
LIT
LIT
1342
1342
LIT
LIT
LIT
LIT
1342
1 342
Ref. Ref.
No.
Description Q'ty Remarks
No.
Description Q'ty Remarks
21 Washer 1 31 Starter Seal 1
22 Split Pin 1 32 Protector 1
23 Starter Lock Wire 1 33 Band 1
24 Cable Holder 1 34 Starter Pulley 1
25 Screw 1 35 Bolt 3
26 Pipe 1 36 Washer 3
27 Starter Roller 1 37 Bolt 3
28 Bolt 1 38 Washer 3
29 Washer 1
30 Collar 1
5-12
2st X50D2 2011
