SECTION 11: FILTER SECTION
35 of 147
Note: In the instructions, an "X" in a part number indicates a digit that changes based on model. Replace
the "X" with a "2" for model 2020; replace the "X" with a "3" for model 2030. For further clarification,
reference the individual table of components for each assembly at the begining of the instructions.
Step 11.3.1
Top Panel
Side (Left) Panel
For Model 2020: On a flat, clean and dry surface, attach the
top panel and side panel of the filter section using five TEK
self-tapping screws.
For Model 2030: On a flat, clean and dry surface, attach the
top panel and side panel of the filter section using seven TEK
self-tapping screws.
Description Part Number
Top Panel 13X05029
Side (Left) Panel 13X05028
TEK Screw 13404
