Inner Support
Rail
Moisture Limiter
Side Cover
Place the moisture limiter inner support rail under the top
flange of the moisture limiter frame side cover and to the top of
the inlet hood. Attach to the top of the inlet hood using nine
#10-24 x ½" bolts and #10-24 nuts. Attach to the side cover of
the frame using two #10-24 x ½" bolts and #10-24 nuts.
Description Part Number
Inner Support Rail 13205097 / 13305097
TEK Screw 13404
#10-24 x 1/2" Bolt 27000
#10-24 Nut 26098
Moisture Limiter
Media
For Model 2020: Insert 4 pieces of 12" (30.5 cm) x
96" (243.8 cm) moisture limiter media from the right
side with the long dimension running top to bottom.
For Model 2030: Insert 5 pieces of 12" (30.5 cm) x
96" (243.8 cm) moisture limiter media from the right
side with the long dimension running top to bottom.
Description Part Number
Moisture Limiter Media 90740002
