Chapter 1: Installation and Initial Configuration
18
Power Meter (PMM) Connectors and Controls
TOP
A
Voltage Measurement.
B
Power
C
Factory Use (Do not connect.)
D
Meter Bus Terminator Switch
E
Meter Bus Connectors. Connects PMM
to Controller.
F
Factory Use (Do not connect.)
G
Multi-conductor Cable CT ABCNE
Connector
H
Meter ID Configuration Switch
BOTTOM
I
Expansion Port. Connects PMM to PMB
