Chapter 3: Using the Web Interface
Schroff LHX/SHX
You must enable the LHX/SHX support for the BCM2 to detect the
presence of a supported Schroff
®
LHX/SHX heat exchanger. See
Miscellaneous
(on page 303).
After enabling the LHX/SHX support and connecting a supported Schroff
®
LHX/SHX heat exchanger to the BCM2, the BCM2 shows the connected
device type in place of 'Feature Port' in the menu -- LHX 20, LHX 40 or
SHX 30.
Note: For connection instructions, see
Connecting a Schroff LHX/SHX
Heat Exchanger
(on page 78).
To open the LHX/SHX page, click 'LHX 20', 'LHX 40' or 'SHX 30' in the
Menu. Then you can monitor and administer the connected LHX/SHX
device with the following.
• Name the heat exchanger
• Monitor LHX/SHX built-in sensors and device states
• Configure the air outlet temperature setpoint
• Configure the default fan speed
• Configure the air temperature/fan speed thresholds (for alert
generation)
• Request maximum cooling using the fan speed and opening the cold
water valve
• Acknowledge alerts or errors remotely, such as failed LHX/SHX
sensors or emergency cooling activation
• Accumulative operating hours
• Indicate the number of power supplies present and whether a
condenser pump is present
Available information/operation is model dependent. For example, only
LHX devices can show sensor alerts. See your LHX/SHX user
documentation for details.
Important: The LHX/SHX settings are stored on the port where the
LHX/SHX device is connected, and are lost if that device is
re-connected to a different BCM2 port.
