Raritan PM Series User Manual

Chapter 3: Using the Web Interface
134
Sensor/Actuator Location Example
Use the X, Y and Z coordinates to describe each sensor's or actuator's
physical location in the data center. See
Individual Sensor/Actuator
Pages (on page 129).
The X, Y and Z values act as additional attributes and are not tied to any
specific measurement scheme. Therefore, you can use
non-measurement values.
Example:
X = Brown Cabinet Row
Y = Third Rack
Z = Top of Cabinet
Values of the X, Y and Z coordinates:
• X and Y: They can be any alphanumeric values comprising 0 to 24
characters.
• Z: When the Z coordinate format is set to
Rack Units , it can be any
number ranging from 0 to 60. When its format is set to
Free-Form , it
can be any alphanumeric value comprising 0 to 24 characters. See .
Feature Port
The FEATURE port supports connection to the following devices.
Device
Description
Asset Strip Raritan asset strips
External
Beeper
An external beeper with the RJ-45 socket.
LHX 20 Schroff
®
LHX-20 heat exchanger.
SHX 30 Schroff
®
SHX-30 heat exchanger.
LHX 40 Schroff
®
LHX-40 heat exchanger.
Power CIM This type represents one of the following Raritan
products:
 Raritan power CIM, D2CIM-PWR. This CIM is used
to connect the BCM2 to the Raritan digital KVM
switch -- Dominion KX II / III.
 Dominion KSX II
 Dominion SX or SX II
