Chapter 2: Connecting External Equipment (Optional)
Daisy-Chain Limitations of Composite Asset Strips
There are some limitations when daisy chaining composite asset strips
"AMS-Mx-Z," where x is a number.
• The maximum cable length between composite asset strips is 2
meters, but the total cable length cannot exceed 10 meters.
• The maximum number of composite asset strips that can be daisy
chained depends on the Raritan product you purchased.
• It is NOT supported to hot swap or hot plug any AMS-Mx-Z in a
composite asset strip chain that has been connected to Raritan's
PDU (or PMC). Therefore, first disconnect the chain from the device
when you need to swap or add any AMS-Mx-Z to the chain.
EMX2-111,
PX2 PDUs,
BCM1 (NOT BCM2
series)
Up to 4 composite asset strips
are supported.
EMX2-888,
PX3 PDUs,
PX3TS transfer
switches
PMC (BCM2 series)
Up to 6 composite asset strips
are supported.
Note for BCM2-iX7 only: In case you hot swap or hot plug any AMS-Mx-Z
in a chain, causing the FEATURE port of the BCM2-iX7 to malfunction,
you can power cycle or reset the BCM2 to restore the FEATURE port.
