NOTE:
You can use SHALLOW
and DEEP alarms . ..or the
FISH
alarms, . ..but not
both types together.
33.I.102
lbe
DEEP Alarm
DEEP water alarm
-
sounds when the water depth is at or greater than the
operator’s preset depth level.
To set a Deep Alarm depth, press
key. On the SELECT ALARM
menu, press the SOUNDER ALARMS
ey.The
SETSOUNDERKLARMS
screen appears, as shown.
Press
the
m
softkey
and then use the
ET
SOUNDER
AIARM!
A
(up)
direction key to set the desired DEEP alarm depth
+su~ucv~
s
level. The
DEEP
alarm digital value is indicated to the
right of
'DEEP"
on the menu and a graphic bar begins
+DEEP
at the bottom right edge of the range scale and rises
60
,
%clIlzV
upward as you press the
1,
(up) direction key. Use the
PRESS”VI(EY
digital value appearing next to
DEE
P
or the end of the
+
flSH
lupl
-
graphic bar to set the desired depth at which the
DEEP
alarm should activate.
+
Ftsu
InOWN)
-
PRESS-TORTURY
Use the
V
(down) direction key to reset the DEEP
alarm if you overshoot the intended set point.
Press
themkey
to return back to the previous display mode.
The alarms are now set. The Alarm bar indicators at the right edge of the
depth scale remain displayed on the fishfmding displays so you can see the
levels at which the alarms are set to activate. When one of the alarms is
activated by the bottom echo, you will see the on-screen blinking alarm
message and hear the audible beeper warning.
If for some reason you do not wish to hear the audio alarm, you can press
the
ALM
keyto
52
turn the buzzer “OFF”. The alarm audio stays inactive until
the a rm condition has been cleared. If the alarm condition re-occurs, the
audio alarm will be re-activated. The buzzer may be permanently turned
OFF in the ALARM menu with the softkey in the menu.
OPERATION 56
