Renesas RL78/F14 User Manual

RL78/F13, F14 CHAPTER 21 INTERRUPT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 1486
Dec 10, 2015
Table 21-2. Flags Corresponding to Interrupt Request Sources (3/4)
Interrupt
Source
Interrupt Request Flag Interrupt Mask Flag Priority Specification Flag
100-pin 80-pin 64-pin 48-pin 32-pin 30-pin 20-pin
Register Register Register
INTLIN0RVC LIN0RVCIF IF1L LIN0RVCMK MK1L LIN0RVCPR0,
LIN0RVCPR1
PR01L,
PR11L
      
INTLIN0STA LIN0STAIF LIN0STAMK LIN0STAPR0,
LIN0STAPR1
      
INTLIN0 LIN0IF LIN0MK LIN0PR0, LIN0PR1
      
INTIICA0 IICAIF0 IICAMK0 IICAPR00, IICAPR10



Note

Note

Note
 
INTP8 PIF8 PMK8 PPR08, PPR18
 

Note

Note
  
INTRTC RTCIF RTCMK RTCPR0, RTCPR1
      
INTRM00 TMIF00 TMMK00 TMPR000, TMPR100
      
INTTM01 TMIF01 TMMK01 TMPR001, TMPR101
      
INTTM02 TMIF02 TMMK02 TMPR002, TMPR102
      
INTTM03 TMIF03 TMMK03 TMPR003, TMPR103
      
INTAD ADIF IF1H ADMK MK1H ADPR0, ADPR1 PR01H,
PR11H
      
INTP6 PIF6 PMK6 PPR06, PPR16
      
INTTM11H TMIF11H TMMK11H TMPR011H, TMPR111H



Note

Note

Note

Note

INTP7 PIF7 PMK7 PPR07, PPR17
      
INTTM13H TMIF13H TMMK13H TMPR013H, TMPR113H
 

Note

Note

Note

Note

INTP9 PIF9 PMK9 PPR09, PPR19
 

Note

Note
  
INTTM01H TMIF01H TMMK01H TMPR001H, TMPR101H
      
INTP10 PIF10 PMK10 PPR10, PPR110
 

Note
   
INTTM03H TMIF03H TMMK03H TMPR003H, TMPR103H
      
INTST1 STIF1 STMK1 STPR01, STPR11
 

Note

Note
  
INTCSI10 CSIIF10 CSIMK10 CSIPR010, CSIPR110
 

Note

Note
  
INTIIC10 IICIF10 IICMK10 IICPR010, IICPR110



Note

Note
  
INTSR1 SRIF1 SRMK1 SRPR01, SRPR11
 

Note

Note
  
INTCSI11 CSIIF11 CSIMK11 CSIPR011, CSIPR111
 

Note

Note
  
INTIIC11 IICIF11 IICMK11 IICPR011, IICPR111



Note

Note
  
INTTM04 TMIF04 TMMK04 TMPR004, TMPR104
      
(Cautions and Note are listed on the next page.)
