Table 8-7. TRDGRji Register Functions in Complementary PWM Mode
Register Setting Register Function PWM
Output Pin
TRDGRA0 — General register. Set the PWM period at initialization.
Setting range:  Value set in TRD0 register
 FFFFh - value set in TRD0 register
Do not write to this register when bits TSTART0 and TSTART1
in the TRDSTR register are set to 1 (count starts).
(TRDIOC0,
output
inverted
every half
period)
TRDGRB0 — General register. Set the changing point of PWM1 output at initialization.
Setting range:  Value set in TRD0 register
 Value set in TRDGRA0 register - value set in TRD0 register
Do not write to this register when bits TSTART0 and TSTART1
in the TRDSTR register are set to 1 (count starts).
TRDIOB0
TRDIOD0
TRDGRA1 — General register. Set the changing point of PWM2 output at initialization.
Setting range:  Value set in TRD0 register
 Value set in TRDGRA0 register - value set in TRD0 register
Do not write to this register when bits TSTART0 and TSTART1
in the TRDSTR register are set to 1 (count starts).
TRDIOA1
TRDIOC1
TRDGRB1 — General register. Set the changing point of PWM3 output at initialization.
Setting range:  Value set in TRD0 register
 Value set in TRDGRA0 register - value set in TRD0 register
Do not write to this register when bits TSTART0 and TSTART1
in the TRDSTR register are set to 1 (count starts).
TRDIOB1
TRDIOD1
TRDGRC0 — (Not used in complementary PWM mode.) —
TRDGRD0 TRDBFD0 = 1 Buffer register. Set the changing point of next PWM1 output
(see 8. 3. 1 (2) Buffer Operation).
Setting range:  Value set in TRD0 register
 Value set in TRDGRA0 register - value set in TRD0 register
Set this register to the same value as the TRDGRB0 register for
initialization.
TRDIOB0
TRDIOD0
TRDGRC1 TRDBFC1 = 1 Buffer register. Set the changing point of next PWM2 output
(see 8. 3. 1 (2) Buffer Operation).
Setting range:  Value set in TRD0 register
 Value set in TRDGRA0 register - value set in TRD0 register
Set this register to the same value as the TRDGRA1 register
for initialization.
TRDIOA1
TRDIOC1
TRDGRD1 TRDBFD1 = 1 Buffer register. Set the changing point of next PWM3 output
(see 8. 3. 1 (2) Buffer Operation).
Setting range:  Value set in TRD0 register
 Value set in TRDGRA0 register - value set in TRD0 register
Set this register to the same value as the TRDGRB1 register
for initialization.
TRDIOB1
TRDIOD1
Caution When the setting of bits TCK2 to TCK0 in the TRDCRi register is 000B (f
CLK, fIH, fPLL, fSUB, and fIL) and
the compare value is set to 0000H, a request signal to the data transfer controller (DTC) and the event
link controller (ELC) is generated only once immediately after the count starts. When the compare
value is 0001H or higher, a request signal is generated each time a compare match occurs.
Remark i = 0 or 1, j = A, B, C, or D
TRDBFD0, TRDBFC1, TRDBFD1: Bits in TRDMR register
