Ricoh aficio 1013F - Exhaust Fan; Main Motor

OTHER REPLACEMENTS
B044/B045/B046 3-32 SM
3.12.4 MAIN MOTOR
1. Rear cover (☛ 3.3.2)
2. Main motor [A] (! × 4, " × 1)
3.12.5 EXHAUST FAN
1. Rear cover (☛ 3.3.2)
2. Exhaust fan [A] (! × 2, " × 1)
B046R919.WMF
B046R918.WMF
[A]
[A]
