Ricoh D009 - Page 587

System SP Table-6
SM Appendix 4-155 D009/D011/D012/D013/D091/D092
Appendix:
Service
Program
Mode Tables
6008 ADF Output Check
001 Pick-up Motor: Fwd
002 Pick-up Motor: Rev
003 Feed Motor: Fwd
004 Feed Motor: Rev
005 Transport Motor: Fwd
007 Inverter Motor: Fwd
008 Inverter Motor: Rev
011 Junction Gate Solenoid
012 Stamp Solenoid
6009
ADF Free Run
Performs an ARDF free run in duplex mode. Press [ON] to start, press [OFF]
to stop.
Note: This is a general free run controlled from the copier.
001 Free Run: Simplex
002 Free Run: Duplex
003 Free Run: Stamp
6010*
ADF Stamp Position
Adjustment
[–5 to 5 / 0 / 0.1 mm step]
Adjusts the horizontal position of the stamp on the scanned originals.
