Ricoh MP C307

1.Installation
4
1. Remove the rear cover [A].
2. Remove the left upper cover [A]. ( x 1)
3. Remove the paper feed tray, and then open the front cover.
4. Remove the left cover [A]. ( x 2)
5. Remove the controller cover [A] with the HDD [B].
