IC Card Reader (External Option)
110
• Connect the USB cable to the USB connector at the left of the mainframe as shown below. Either
connector can be used.
• Obtain these clamps [A] in advance, because they are not included in this kit.
When Installing in a Machine That Has a 1-Bin Tray Unit
1. Remove the following items.
• Scanner unit and ADF. (Scanner Unit with the ADF)
• 1-bin tray unit (1-Bin Tray BN1030 (D574-58))
