IC Card Reader (External Option)
111
2. Attach the IC card reader [A] to the rear of the front right cover [B] with the bracket [C]. ( × 1 included
in this kit)
• The bracket [C] is different from that of the base machine. The bracket for the base machine
cannot be used. Consult your supervisor to obtain the correct bracket.
3. Route the USB cable [A] from the IC card reader as shown below, and then pull out the USB cable from
the rear of the machine.
To Next Page
