Ricoh MP C307

NFC Card Reader Type M13 (D3AC-21)
115
4. Make a loop with the USB cable of the NFC reader, and then attach the ferrite core [A].
5. Connect the USB cable to the operation panel.
6. Attach the cover removed in step 3.
• Fit the cable into the slit [A] in the cover.
