Ricoh MP C307

NFC Card Reader Type M13 (D3AC-21)
116
7. Attach the hinge cover [A].
• Fit the cable into the slit.
8. Attach the fasteners to the front side of the NFC reader [A].
9. Attach the NFC reader [A] to the back side of the front right cover with adhesive tape.
